Haltech WB2 - Dual Channel O2 Wideband Controller Kit
WB2 Bosch - Dual Channel CAN O2 Wideband Controller Kit Length: 1.2M (4ft)
US$515
+ US$0 for the , once however many gauges. Buying more than one? The rest daisy-chain on XH4 leads. Additional OBD cables can be bought separately in the accessories section.
Approximate — this gauge is priced in New Zealand dollars at NZ$919, and Stripe converts to your currency at checkout.
The Haltech WB2 is a dual-channel CAN wideband controller for two Bosch LSU 4.9 sensors, with a 1.2m (4ft) harness. Paired with a KrispyGauge it shows live AFR and lambda for each bank, updated 20 times a second, with a full-screen warning if either side goes lean.
No Haltech ECU needed. KrispyGauge reads the WB2 directly over CAN, so it works on a car with a factory ECU, alongside a Haltech or other supported ECU, or with no CAN-capable ECU at all. On a Haltech Nexus, Elite or Platinum ECU the WB2 also feeds the ECU, and is set up in NSP, ESP or ECU Manager.
- Two sensors: for V6 and V8 engines, twin-turbo setups, or anywhere you want to see each bank separately. For one sensor, see the WB1.
- Bosch LSU 4.9 sensor version
- Connects with DTM-4 CAN cables and a CAN hub
- On the gauge: choose WB2 device A, B, C or D under Settings to match the controller, and set the CAN bus to 1 Mbit/s. Channel 1 also drives the gauge's main AFR reading.
Wiring, setup and FAQs are in our Haltech WB1 / WB2 wideband gauge guide. KrispyGauge's wideband support is currently in beta.
Secure checkout by Stripe. Cards, Apple Pay and Google Pay accepted. Questions? Get in touch.
Shipping calculated at checkout.
